DeWALT
KIT NAILER FRAMING CORDLESS 2 TO 3-1/2IN
kit nailer framing cordless 2 to 3-1/2in
Stellar Part #DEWAL DCN692M1
MFG Part #DCN692M1
MFG Name:Stanley Black & Decker
Product Description:
DeWALT DCN692M1 XR High Performance Cordless Framing Nailer Kit, 2 to 3-1/2 in Fastener, 55 Nails Magazine, 16 in OAL, Battery
Login For Price
- Item Features
- Technical Specifications
- Brushless motor and engine design provides enough power-to drive 3-1/2 in nails
- Angled magazine
- Bump/sequential nailer operating mode
- Sequential operating mode allows for precision placement and the bump operating mode provides the user with production speed
- Dual speed optimizes motor speed for different nail lengths
- Easy access to the nosepiece for the removal of jammed nails
- Trigger lock-off allows trigger to be disabled when tool is not in use
- Top cap is impact resistant and easy to remove for troubleshooting
- Accepts 30 to 34 deg paper tape nails, clipped head or offset full round head
- Stall release lever quickly resets the drive blade
- 0.113 to 0.131 ga Dia nail
- Brushless motor and engine design provides enough power-to drive 3-1/2 in nails
- Angled magazine
- Bump/sequential nailer operating mode
- Sequential operating mode allows for precision placement and the bump operating mode provides the user with production speed
- Dual speed optimizes motor speed for different nail lengths
- Easy access to the nosepiece for the removal of jammed nails
- Trigger lock-off allows trigger to be disabled when tool is not in use
- Top cap is impact resistant and easy to remove for troubleshooting
- Accepts 30 to 34 deg paper tape nails, clipped head or offset full round head
- Stall release lever quickly resets the drive blade
- 0.113 to 0.131 ga Dia nail
- Bare Tool/Kit:KitBattery Capacity:4 AhBattery Included:YesBattery Type:Lithium-IonCollation Angle:33 degCollation Type:PaperColor:YellowControl Type:Trigger Lock-OffDimensions:4-45/64 in W x 13-3/4 in HFastener Size:2 to 3-1/2 inHandle Type:Contoured/OvermoldHousing Material:PlasticMagazine Capacity:55 NailsMagazine Loading:Rear LoadOverall Length:16 inPower Source:BatterySeries:XR, XR„¢, XR™Shank Size:0.113 to 0.131 inTip Type:Non-MarringTrigger Type:Sequential/BumpType:High PerformanceVoltage Rating:20 VDC
