Sandvik Coromant

CHUCK AND HLDR TOOL HC C8 1.26IN 2.677IN

chuck and hldr tool hc c8 1.26in 2.677in

Stellar Part #SANCO 6872186

MFG Part #6872186

MFG Name:Sandvik Coromant

Product Description:

Sandvik Coromant 6872186 CoroChuck 930 Heavy Duty High Precision Hydraulic Tool Holder and Chuck, PSC Taper Shank, C8 Connection, 1.26 in Dia Hole, 2.677 in Dia Nose, 7.087 in Projection

Technical Specifications

ANSI Code:

930-C8-HD-32-180

Clamping Depth:

2.007 in

Connection Size:

Hole Diameter:

1.26 in

ISO Code:

930-C8-HD-32-180

Nose Diameter:

2.677 in

Overall Length:

8.976 in

Projection:

7.087 in

Series:

CoroChuck™ 930

Shank Type:

Coromant® Capto®

System Size Machine Side:

Taper Size:

3.15 in

Through Coolant (Yes/No):

Yes

Type:

Heavy Duty High Precision

: ANSI Code:
930-C8-HD-32-180
Clamping Depth:
2.007 in
Connection Size:
C8
Hole Diameter:
1.26 in
ISO Code:
930-C8-HD-32-180
Nose Diameter:
2.677 in
Overall Length:
8.976 in
Projection:
7.087 in
Series:
CoroChuck™ 930
Shank Type:
Coromant® Capto®
System Size Machine Side:
C8
Taper Size:
3.15 in
Through Coolant (Yes/No):
Yes
Type:
Heavy Duty High Precision
