Sandvik Coromant

INSERT NOSE BALL R216 2504 CARBIDE 2040

insert nose ball r216 2504 carbide 2040

Stellar Part #SANCO 5743684

MFG Part #5743684

MFG Name:Sandvik Coromant

Product Description:

Sandvik Coromant 5743684 CoroMill 216 Single Sided Ball Nose Insert, ANSI Code: R216-25 04 M-M 2040, R216 Insert, 2504 Insert, Carbide, Manufacturers Grade: 2040, Round Shape, Material Grade: M, P, S

UOM:

Technical Specifications
Resources

ANSI Code:

R216-25 04 M-M 2040

Chipbreaker:

M-M

Finish:

CVD-TiCN+Al2O3+TiN Coated

Hand of Insert:

Right

Hole Diameter:

0.185 in

Inscribed Circle:

3/4 in

Insert Size:

2504

Insert Style:

R216

ISO Code:

R216-25 04 M-M 2040

Lead Angle:

9 deg

Manufacturer's Grade:

2040

Material:

Carbide

Material Application:

Steel, Stainless Steel and Titanium Alloys

Material Grade:

M, P, S

Rake:

Positive

Series:

CoroMill® 216

Shape:

Round

Thickness:

0.187 in

Type:

Single Sided

Width:

3/4 in

: ANSI Code:
R216-25 04 M-M 2040
Chipbreaker:
M-M
Finish:
CVD-TiCN+Al2O3+TiN Coated
Hand of Insert:
Right
Hole Diameter:
0.185 in
Inscribed Circle:
3/4 in
Insert Size:
2504
Insert Style:
R216
ISO Code:
R216-25 04 M-M 2040
Lead Angle:
9 deg
Manufacturer's Grade:
2040
Material:
Carbide
Material Application:
Steel, Stainless Steel and Titanium Alloys
Material Grade:
M, P, S
Rake:
Positive
Series:
CoroMill® 216
Shape:
Round
Thickness:
0.187 in
Type:
Single Sided
Width:
3/4 in
